Henan Tianzhong is a leading brand specializing in the manufacturing of dewatering screw press, solid-liquid separators, vegetable pulping machines, screw conveyors, and trash can lifters, etc.We are an integrated solution provider of dehydration and reduction of waste material in various industries,R&D,production and sales of complete sets of fine filtration equipmenet.Choose our OEM/ODM services for a combination of speed and quality.Tianzhong Machinery,You First Option, Longlife Benefit!

Brief Description:

The PC and CPJ stainless steel crusher are custom-designed hammer mills,specifically designed for the crushing of fruits and vegetables.such as :apple,pear,kiwi,carrot,pawpaw,potato etc.

PS series fruits crusher machine is suitable for crushing a small-yield fruits and vegetables.At the same time, it can also treat pre-cooked softened poem fruits and vegetable are crushed, and the crushing particle size is 5-8mm.

Different juicing methods require different sizes of fruit pulp,so the crushed fruit particles should be controlled between3-5mm.

After crushing,the particle size should not exceed10mm,and pulp particle size can be controlled by the aperture of the sieve plate.

Working principle:

The machine is mainly composed of a feeding hopper,crushing parts,brackets,discharginghopper,transmission parts etc. The parts contacting materials are all made of stainless steel.The flying knife is driven by the motor rotate around its axis in the fixed bottom knife gap,so that the fruits and vegetable are broken.

Additionally,the blade is very easy to clean and disassemble.

Technical parameter:

Model PS-1 PS-3 CPJ-5 CPJ-10 GPJ-20
Capacity(t/h) 0.5-1t/h 2-3t/h 3-5t/h 7-10t/h 15-20t/h
Power(kw) 0.55kw 1.5kw 11kw 15kw 22kw
Weight(t) 150kg 260kg 650kg 9500kg 1200kg
Diemensions(mm) 450*430*1000 650*500*1160 1200*800*1500 1400*1000*1900 1500*1200*2200
