Brief Description:

Screw type juice extractor ,also as know as cold press juice is primarily used for extracting juice from fruits and vegetables.such as apples,pineapples,ginger,carrots,oranges,pears,blueberries,tomatoes,  spinach,and coconut meat after they have been crushed.

It operates at a slower speed and uses a screw to crush and press the produce.After juice extraction,the materials moisture content is about 60%(varies depending on the material)

  1. Spiral press juice machine is an ideal choice for squeezing a variety of fruits and vegetables.including apples,grapes,berries,pears,carrots,tomatoes,spinach,celery etc.
  2. Except for the transmission parts,the remainder of the device is fabricated from food-grade stainless steel.
  3. Extracted juice is separated from waste automatically.

Technical parameter:

Model Processing Capacity Power Dimensions(mm) Speed of screw(rpm) Mesh opening size
LZ-0.5 0.5t/h 1.5kw 910*385*810 Approx. 410 0.3-2.0 mm, can be customized as per specific requirements
LZ-1.5 1.5t/h 4.0kw 1300*500*1330
LZ-2.5 2.5t/h 11kw 1480*740*1780
The following models are equipped with shredders
PZJ-0.5 0.5t/h 2.05kw 910*500*1250 Approx. 410 0.3-2.0 mm, can be customized as per specific requirements
PZJ-1.5 1.5t/h 5.1kw 1300*650*1380
PZJ-2.5 2.5t/h 12.5kw 1500*700*2000

Working principle:

The screw type juice extractor consists of a drive system,feed hopper,screen,screw,juice tank,and residue outlet.

The main component of the equipment is the screw. The bottom diameter increases gradually along the direction of slag outlet and the screw pitch decreases gradually. When the material is pushed by the screw, the material is pressed due to the reduction of the volume of the screw cavity.

Application:

Applicability of this machine can be widely used for squeezing pineapple,apple, pear and other fruits;mulberry,grape,orange and other berries;tomato,ginger,garlic,celery and other vegetables.

It is widely used in the fruit processing industry,food and beverage processing plant.

Detailed photos:

Large Material Inlet: put the raw material into the hopper ,spiral propels under compression, the juice is squeezed from the pulp through filter screen and flowing into the juice holding device at the bottom.The pressing strength be adjusted by handwheel at the end of extractor.

Meticulous Screen:Its made of form bearing,feeder hopper,screw,filter screen,juice holding device,the rear bearing,slag notch and other parts.

Residue Outlets:Residues such as peel and pulp are discharge from this outlet.The angle of this outlet can be adjusted to adapt to unused screen

Juice Outlets:Use food grade stainless steel to ensure the cleanliness of the finished product.The direction and length of the guide pipe can be customized for easier loading and unloading.
