Brief Description:

Variable diameter screw press is a type of dehydration equipment that utilizes physical extrusion and a spiral with varying diameters and pitches for dehydration.It finds extensive application across various industries,including wastewate treatment,agricultural waste processing,the pulp and paper industry,and the processing of herbal residues, as well as domestic waste and fruit waste.Moreover, it is also used for extracting juice from a wide array of fruits and vegetables, especially those with comparatively lower fiber conten.

Working principle:

It consists of a motor drive system,feed hopper,spiral propeller,screen,blocker,collection tank,support frame,hydraulic cylinder and other parts.

Material enters the inner spiral of the equipment through the feed box. Under the propulsion of a spiral propeller, it is subjected to increasing pressure due to the variable diameter and distance, which forms the first squeeze.then,they are subjected a second squeezing through the resistance conical body.During operation, the excess moisture is forced out through the mesh holes as fluids, and is collected and discharged through the outlet.The material that has been squeezed out of water is continuously conveyed by a spiral propeller and pushed out through the blocker,thereby discharging slag from the outlet.

Technical parameter:

Model DYZJ-350 DYZJ-420 DYZJ-550 DYZJ-630 DYZJ-760
Motor Power 11KW 15KW 22KW 30KW 45KW
Hydraulic Power 1.5KW 1.5KW 1.5KW 2.2KW 2.2KW
Voltage 380V / 50HZ
Screw Diameter φ350mm φ420mm Φ500mm Φ630mm Φ760mm
ScreenOpening Size 0.5/0.8/1/2/3/4/5mm or can be customized
Processing Capacity 2-3t/h 3-5t/h 7-8t/h 10-12t/h 16-18t/h
Equipment Material                               The parts in contact material 304 stainless steel
Equipment Weight 1800kg 2400kg 3000kg 4500kg 5700kg
Dimensions 360*82*130cm 420*82*150cm 480*90*160cm 560*110*175cm 680*120*185cm

Application:

A single screw press can process a wide range of materials. Its primary function is to compress materials to extract liquids from solids. The following materials are suitable for processing with a single screw press.

Variable diameter screw press is capable of handling a diverse array of materials.Its principal role is to compress materials and to extract liquids from solids.The following are examples of materials that be processed via a single screw press.

Fruits and Vegetables:It is suitable for extracting juice form fruits and vegetables that contain fiber,such as apples,grapes(including their skin),berries,oranges,carrots,tomatoes,cabbages,gingers,spinach,and more.its can also dispose of waste fruits and vegetables for reducing the volume and weight.

Biomass and Fibrous Materials:Variable diameter screw press are capable of processing biomass materials, like wood chips, sawdust, as well as agricultural residues such as corn husks, straws, and grass.

Dehydration of various manure: These presses are capable of processing animal manure, like cow dung, pig manure, poultry litter, andduck manure, typically for the purpose of dewatering the liquid manure.

Other:Filter residue,diaper waste, cellulose, medical waste,rubber waste,paper pulp, plastic.it is highly effective in the dewatering of diverse waste residues,such as herbal residues,brewers gains,sauce residues,and coffee residues.However,it is important to know that the material should process fibers with particle size exceeding 1.5mm.Please be advised that this machine is not suitable for material without fibers.

Overall,the Variable diameter screw press offers a versatile and efficient solution for the separation and dewatering of solid-liquid mixtures across various industries,especially in applications like fruit juice extraction,animal waste processing,and the handling devise waste residues.Should you require further information,do not hesitate to contact us!
